泥河湾盆地山神庙咀遗址早更新世中-小型牛科动物化石新材料

doi:10.19615/j.cnki.2096-9899.220413

摘要/Abstract

摘要：

山神庙咀是泥河湾盆地新发现的早更新世遗址,该遗址产出丰富多样的哺乳动物化石,其中包括如下属种的中-小型牛科动物：翁氏转角羚羊(Spirocerus wongi), 中国羚羊(Gazella sinensis), 山东绵羊(Ovis shantungensis)和皮氏巨羊(Megalovis piveteaui); 中国羚羊是其中化石最丰富者。前两种化石主要以角心和头骨及下颌为主,此外,4个种都有掌骨和/或蹠骨发现。依据角心特征不难将有关类别鉴定到种一级,而对于牙齿及头后骨骼而言,要想确切鉴定是有一定困难的。在头后骨骼中,掌、蹠骨最值得关注,它不仅对属种鉴定有重要价值,而且对重建系统演化关系及解释古生态适应都是重要证据。修正了前人错误鉴定的泥河湾牛科动物的掌、蹠骨。山神庙咀动物群中的牛科动物以羚羊和野牛为主,表明泥河湾盆地在早更新世期间以草原环境为主导。

关键词: 泥河湾山神庙咀, 早更新世, 中-小型牛科动物, 新化石

Abstract:

Shanshenmiaozui site in Nihewan Basin in North China is a recently discovered Early Pleistocene site which yields rich and diverse mammalian fossils. In the fauna, the small and medium-sized bovid fossils are well represented and can be referred to the following taxa: Spirocerus wongi, Gazella sinensis, Ovis shantungensis and Megalovis piveteaui respectively, among which G. sinensis is the dominate species. S. wongi and G. sinensis are mainly represented by horn-cores and partial skull bones as well as mandibles; in addition, metacarpal and/or metatarsal bones were also recognized for all of the four species. The horn-cores are easy to be identified to the species level, while the dentitions and the postcranial bones underwent a series of examinations and comparisons before getting properly determined and referred to the most approximate taxa. Among the postcranial bones, the metapodials, especially to the metacarpal bones special attentions were paid, which are crucial not only for taxonomic identification, but also for phylogenetic and paleoecological reconstructions; the previously misidentified metapodial specimens in Nihewan fauna were reconsidered in this paper. In the SSMZ fauna, the bovid guild is dominated by Gazella and Bison, which indicates steppe was the most important biome in Nihewan Basin during Early Pleistocene.

Key words: Shanshenmiaozui,Nihewa,China, Early Pleistocene, small-medium bovid, new fossils

中图分类号:

Q915.876

同号文, 张贝, 陈曦, 王晓敏. 泥河湾盆地山神庙咀遗址早更新世中-小型牛科动物化石新材料. 古脊椎动物学报, 2022, 60(2): 134-168.

TONG Hao-Wen, ZHANG Bei, CHEN Xi, WANG Xiao-Min. New fossils of small and medium-sized bovids from the Early Site of Shanshenmiaozui in Nihewan Basin, North China. Vertebrata Palasiatica, 2022, 60(2): 134-168.

图/表 17

参考文献 85

[1]	Bai W P, Dong W, Zhang L M, et al. 2019. New material of the Early Pleistocene spiral horned antelope Spirocerus (Artiodactyla, Mammalia) from North China and discussion on its evolution. Quat Int, 522: 94-102 DOI URL
[2]	Bärmann E V, Rössner G E, 2011. Dental nomenclature in Ruminantia: towards a standard terminological framework. Z Säugetierkd, 76(6): 762-768
[3]	Bohlin B, 1938. Einige Jungtertiäre und Pleistozäne Cavicornier aus Nord-China. Nova Acta Reg Soc Sci Upsala, Ser IV, 11(2): 1-54
[4]	Boule M, Breuil H, Licent E, et al. 1928. Le Paléolithique de la Chine. Arch Inst Paléontol Hum, Mém, 4: 1-138
[5]	Brown C L, Gustafson C E, 1979. A key to postcranial skeletal remains of cattle/bison, elk, and horse. Rep Invest Wash State Univ, Lab Anthropol, 57: 1-199
[6]	Castelló J R, 2016. Bovids of the World:Antelopes, Gazelles, Cattle, Goats, Sheep, and Relatives. Princeton: Princeton University Press. 1-664
[7]	Chen G F, 1997. The genus Gazella Blainville, 1816 (Bovidae, Artiodactyla) from the Late Neogene of Yushe Basin, Shanxi Province, China. Vert PalAsiat, 35(4): 233-249
[8]	Chen X, Tong H W, 2017. On the hindfoot bones of Mammuthus trogontherii from Shanshenmiaozui in Nihewan Basin, China. Quat Int, 445: 50-59 DOI URL
[9]	Colbert E H, Hooijer D A, 1953. Pleistocene mammals from the limestone fissures of Szechuan, China. Bull Am Mus Nat Hist, 102(1): 1-134
[10]	Crégut-Bonnoure E, 1984. The Pleistocene Ovibovinae of western Europe: temporo-spatial expansion and paleoecological implications. Biol Pap Univ Alaska Spec Rep, 4: 136-144
[11]	Demircioglu I, Ince N G, 2020. Three-dimensional modelling of computed tomography images of limb bones in gazelles (Gazella subgutturosa). Anat Hist Embryol, 49: 695-707
[12]	Dong W, Li Z Y, 2008. Late Pleistocene Artiodactyla (Mammalia) from the Lingjing site, Xuchang, Henan Province (China). Vert PalAsiat, 46(1): 31-50
[13]	Dong W, Fang Y S, Zhang Z H, 2007. Artiodactyla Owen, 1848. In: Fang Y S, Dong W eds. The Early Pleistocene Mammalian Fauna at Tuozi Cave, Nanjing, China. Beijing: Science Press. 85-129
[14]	Dong W, Fu R Y, Feng X W, et al. 2009. Late Pleistocene mammalian fauna from the Mashandong, Chaoyang, Liaoning Province. Acta Anthropol Sin, 28: 95-109
[15]	Driesch A von den, 1976. A guide to the measurement of animal bones from archaeological sites. Bull Peabody Mus, 1: 1-137
[16]	Duvernois M-P, Guérin C, 1989. Les Bovidae (Mammalia, Artiodactyla) du Villafranchien supérieur d’Europe occidentale. Geobios, 22: 339-379 DOI URL
[17]	Farke A A, 2010. Evolution and functional morphology of the frontal sinuses in Bovidae (Mammalia: Artiodactyla), and implications for the evolution of cranial pneumaticity. Zool J Linn Soc, 159: 988-1014 DOI URL
[18]	Fedosenko A K, Blank D A, 2005. Ovis ammon. Mamm Spec, 773: 1-15 DOI URL
[19]	Gee H, 1993. The distinction between postcranial bones of Bos primigenius Bojanus, 1827 and Bison priscus Bojanus, 1827 from the British Pleistocene and the taxonomic status of Bos and Bison. J Quat Sci, 8(1): 79-92 DOI URL
[20]	Gentry A W, 1966. Fossil Antilopini of East Africa. Bull Br Mus Nat Hist Geol, 12(2): 45-106
[21]	Gentry A W, 1992. The subfamilies and tribes of the family Bovidae. Mamm Rev, 22(1): 1-32 DOI URL
[22]	Gentry A W, 2010. Chapter 38:Bovidae. In: Werdelin L, Sanders W J eds. Cenozoic Mammals of Africa. Berkeley: University of California Press. 747-803
[23]	Gromova V, 1960. A Key to the Large Long Bones of Mammals. (Liu H Y trans). Beijing: Science Press. 1-162
[24]	Groves C, 2014. Current taxonomy and diversity of crown ruminants above the species level. Zitteliana B, 32: 5-14
[25]	Grubb P, 2001. Review of family - group names of living bovids. J Mammal, 82(2): 374-388 DOI URL
[26]	Han D F, 1987. Artiodactyla fossils from Liucheng Gigantopithecus Cave in Guangxi. Mem Inst Vert Paleontol Paleoanthropol, Acad Sin, 18: 135-208
[27]	Hassanin A, Delsuc F, Ropiquet A, et al. 2012. Pattern and timing of diversification of Cetartiodactyla (Mammalia, Laurasiatheria), as revealed by a comprehensive analysis of mitochondrial genomes. Compt Rend Biol, 335: 32-50 DOI URL
[28]	Hermier R, Merceron G, Kostopoulos D S, 2020. The emblematic Eurasian Villafranchian antelope Gazellospira (Mammalia: Bovidae): new insights from the Lower Pleistocene Dafnero fossil sites (northern Greece). Geobios, 61: 11-29 DOI URL
[29]	Janis C M, Lister A, 1985. The morphology of the lower fourth premolar as a taxonomic character in the Ruminantia (Mammalia; Artiodactyla), and the systematic position of Triceromeryx. J Paleontol, 59(2): 405-410
[30]	Jiang Z G, 2004. Przewalski’s Gazelle. Beijing: China Forestry Publishing House. 1-251
[31]	Jin C Z, Wang Y, Liu J Y, et al. 2021. Late Cenozoic mammalian faunal evolution at the Jinyuan Cave site of Luotuo Hill, Dalian, Northeast China. Quat Int, https://doi.org/10.1016/j.quaint.2021.01.011
[32]	Jin X S, Wu W T, Du T M, 1994. The discovery and study of Gazelle skull fossil in Zhejiang. Geol Zhejiang, 10(2): 1-4
[33]	Kahlke H D, 1961. Revision der Säugetierfaunen der klassischen deutschen Pleistozän-Fundestellen von Süßenborn, Mosbach und Taubach. Geologie, 10: 493-532
[34]	Kahlke H D, 1964. Early Middle Pleistocene (Mindel/Elster) Praeovibos and Ovibos. Comment Biol, 26(5): 1-17
[35]	Kahlke R D, 1999. The history of the origin, evolution and dispersal of the Late Pleistocene Mammuthus-Coelodonta faunal complex in Eurasia (large mammals). Rapid City: Fenske Companies. 1-219
[36]	Kostopoulos D S, 2004. Revision of some Late Miocene spiral horned antelopes (Bovidae, Mammalia). Neues Jahrb Geol Palaeont Abh, 231(2): 167-190
[37]	Kuznetsova M V, Kholodov M V, 2003. Revision of phylogenetic relationships in the Antilopinae Subfamily on the basis of the mitochondrial rRNA and β-Spectrin nuclear gene sequences. Dokl Biol Sci: Proc Acad Sci USSR, Biol Sci Sect, 391(1-6): 333-336
[38]	Li Y K, Shi Q Q, Chen S K, et al. 2018. “Gazella” (Mammalia: Bovidae) from the Late Miocene Qingyang area, Gansu, China. Palaeont Electron, 21.2.24A: 1-27, https://doi.org/10.26879/838
[39]	Licent E, Trassaert M, 1935. The Pliocene lacustrine series in central Shansi. Bull Geol Soc China, 14: 211-220 DOI URL
[40]	Lister J A, 1985. The morphology of the lower fourth premolar as a taxonomic character in the Ruminantia (Mammalia; Artiodactyla), and the systematic position of Triceromeryx. J Paleontol, 59(2): 405-410
[41]	Liu P, Deng C, Li S, et al. 2012. Magnetostratigraphic dating of the Xiashagou Fauna and implication for sequencing the mammalian faunas in the Nihewan Basin, North China. Palaeogeogr Palaeoclimatol Palaeoecol, 315: 75-85
[42]	Maniakas I, Kostopoulos D S, 2017. Morphometric-palaeoecological discrimination between Bison populations of the western Palaearctic. Geobios, 50: 155-171 DOI URL
[43]	Matsumoto H, 1926. On a new fossil race of bighorn sheep from Shantung, China. Sci Rep Tôhoku Imp Univ, Ser 2 (Geol), 10: 39-41
[44]	Matthee C A, Davis S K, 2001. Molecular insights into the evolution of the Family Bovidae: a nuclear DNA perspective. Mol Biol Evol, 18(7): 1220-1230 PMID
[45]	McKenna M C, Bell S K, 1997. Classification of Mammals Above the Species Level. New York: Columbia University Press. 1-631
[46]	Pilgrim G E, 1939. The fossil Bovidae of India. Palaeontol Ind New Ser, 26(1): 1-356
[47]	Prat F, 1966a. Les capridés. In: Lavocat R ed. Atlas de Préhistoire. Tome III. Faunes et flores préhistoriques de l’Europe occidentale. Paris: N. Boubée et cie (L’Homme et ses origines). 279-322
[48]	Prat F, 1966b. Les antilopes. In: Lavocat R ed. Atlas de Préhistoire. Tome III. Faunes et flores préhistoriques de l’Europe occidentale. Paris: N. Boubée et cie (L’Homme et ses origines). 323-336
[49]	Qiu Z X, 2006. Quaternary environmental changes and evolution of large mammals in North China. Vert PalAsiat, 44(2): 109-132
[50]	Radulesco C, Samson P, 1962. Sur la présence de Megalovis latifrons dans le Villafranchien d'Olténie (Roumanie). Vert PalAsiat, 6(3): 262-269
[51]	Ratajczak U, Shpansky A V, Malikov D G, et al. 2016. Quaternary skulls of the saiga antelope from eastern Europe and Siberia: Saiga borealis versus Saiga tatarica - one species or two? Quat Int, 420: 329-347 DOI URL
[52]	Reshetov V, Sukhanov V B, 1979. Postcranial skeleton. In: Sokolov V E ed. European Bison―Morphology, Systematics, Evolution, Ecology. Moscow: Nauka Publishers. 142-173
[53]	Schaub S, 1937. Ein neuer Cavicornier aus dem Oberpliocaen von Honan. Bull Geol Inst Univ Upps, 27: 25-31
[54]	Scott K M, 1985. Allometric trends and locomotor adaptations in the Bovidae. Bull Am Mus Nat Hist, 179: 197-288
[55]	Sher A V, 1997. An early Quaternary bison population from Untermassfeld: Bison menneri sp. nov. In: Kahlke R-D ed. Das Pleistozän von Untermassfeld bei Meiningen (Thüringen), Teil 1. Monogr Romisch-German Zentralmus Mainzer, 40(1): 101-180
[56]	Smith A T, Xie Y, 2008. A Guide to the Mammals of China. Princeton: Princeton University Press. 1-576
[57]	Sokolov I I, 1953. A primer of natural classification of Cavicorns (Bovidae). Proc Zool Inst Acad Sci USSR, 14: 1-295
[58]	Sokolov I I, 1959. On the postcranial skeleton and the outward appearance of Spirocerus kiakhtensis M. Pavlova. Vert PalAsiat, 3(1): 23-33
[59]	Sokolov V E, Lushchekina A A, 1997. Procapra gutturosa. Mamm Spec, 571: 1-5
[60]	Tedford R H, Flynn L J, Qiu Z X, et al. 1991. Yushe Basin, China: paleomagnetically calibrated mammalian biostratigraphic standard for the Late Neogene of eastern Asia. J Vert Paleont, 11(4): 519-526 DOI URL
[61]	Teilhard de Chardin P, Leroy P, 1942. Chinese fossil mammals: a complete bibliography, analyzed, tabulated, annotated and indexed. Inst Geo-Biol Pék, 8: 1-142
[62]	Teilhard de Chardin P, Piveteau J, 1930. Les mammifères fossiles de Nihowan (Chine). Ann Paléontol, 19: 1-134
[63]	Teilhard de Chardin P, Trassaert M, 1938. Cavicornia of south-eastern Shansi. Palaeontol Sin, New Ser C, 6: 1-98
[64]	Teilhard de Chardin P, Young C C, 1936. On the mammalian remains from the archaeological site of Anvang. Palaeontol Sin, Ser C, 1: 1-61
[65]	Tong H W, 2012. New remains of Mammuthus trogontherii from the Early Pleistocene Nihewan beds at Shanshenmiaozui, Hebei. Quat Int, 255: 217-230 DOI URL
[66]	Tong H W, Chen X, 2016. On newborn calf skulls of Early Pleistocene Mammuthus trogontherii from Shanshenmiaozui in Nihewan Basin, China. Quat Int, 406: 57-69 DOI URL
[67]	Tong H W, Wang X M, 2014. Juvenile skulls and other postcranial bones of Coelodonta nihowanensis from Shanshenmiaozui, Nihewan Basin, China. J Vert Paleont, 34(3): 710-724 DOI URL
[68]	Tong H W, Zhang B, 2019. New fossils of Eucladoceros boulei (Artiodactyla, Mammalia) from Early Pleistocene Nihewan Beds, China. Palaeoworld, 28(3): 403-424 DOI URL
[69]	Tong H W, Hu N, Han F, 2011. A preliminary report on the excavations at the Early Pleistocene fossil site of Shanshenmiaozui in Nihewan Basin, Hebei, China. Quat Sci, 31: 643-653
[70]	Tong H W, Hu N, Wang X M, 2012. New remains of Canis chihliensis (Mammalia, Carnivora) from Shanshenmiaozui, a Lower Pleistocene Site in Yangyuan, Hebei. Vert PalAsiat, 50(4): 335-360
[71]	Tong H W, Wang F G, Zheng M, et al. 2014. New fossils of Stephanorhinus kirchbergensis and Elasmotherium peii from the Nihewan Basin. Acta Anthropol Sin, 33(3): 369-388
[72]	Tong H W, Chen X, Zhang B, 2017. New fossils of Bison palaeosinensis (Artiodactyla, Mammalia) from the steppe mammoth site of Early Pleistocene in Nihewan Basin, China. Quat Int, 445: 250-268 DOI URL
[73]	Tong H W, Chen X, Zhang B, 2018. New postcranial bones of Elasmotherium peii from Shanshenmiaozui in Nihewan Basin, northern China. Quaternaire, 29 (3): 195-204
[74]	Tong H W, Zhang B, Chen X, et al. 2021. Chronological significance of the mammalian fauna from the Early Pleistocene Shanshenmiaozui site in Nihewan Basin, northern China. Acta Anthropol Sin, 40(3): 469-489
[75]	Tong Y S, Zheng S H, Qiu Z D, 1995. Cenozoic mammal ages of China. Vert PalAsiat, 33(4): 290-314
[76]	Viret J, 1954. Le Loess à bancs durcis de Saint-Vallier (Drôme) et sa faune de mammifères villafranchiens. Nouv Arch Mus Hist Nat Lyon, 4: 1-200
[77]	Vislobokova I A, 2008. The major stages in the evolution of Artiodactyl communities from the Pliocene-Early Middle Pleistocene of northern Eurasia. Paleontol J, 42(3):297-312; 42(4): 414-424 DOI URL
[78]	Vislobokova I A, Titov V V, 2020. Spiral-horned antelopes of the Early Pleistocene Tamanian faunal complex of eastern Europe. Russ J Theriol, 19(1): 37-44 DOI URL
[79]	Vislobokova I, Dmitrieva E, Kalmykov N, 1995. Artiodactyls from the Late Pliocene of Udunga, western trans-Baikal, Russia. J Vert Paleontol, 15: 146-159 DOI URL
[80]	Vislobokova I A, Titov V V, Lavrov A V, et al. 2020. Early Pleistocene spiral-horned antelopes (Artiodactyla, Bovidae) from the Taurida Cave (Crimea, Russia). Paleontol J, 54: 81-90 DOI URL
[81]	Vrba E S, Schaller G, 2000. Phylogeny of Bovidae based on behavior, glands, skulls, and postcrania. In: Vrba E S, Schaller G eds. Antelopes, Deer, and Relatives. New Haven: Yale University Press. 203-222
[82]	Wang Y R, Peters J, Barker G, 2020. Morphological and metric criteria for identifying postcranial skeletal remains of modern and archaeological Caprinae and Antilopinae in the northeast Tibetan Plateau and adjacent areas. Int J Osteoarchaeol, 30(4): 492-506 DOI URL
[83]	Young C C, 1932. On the Artiodactyla from the Sinanthropus Site at Choukoutien. Palaeontol Sin Ser C, 8(2): 1-100
[84]	Zhang Z Q, Yang R, 2016. Morphology and taxonomy of Gazella (Bovidae, Artiodactyla) from the Late Miocene Bahe Formation, Lantian, Shaanxi Province, China. Vert PalAsiat, 54(1): 1-20
[85]	Zhu R X, Hoffman K A, Potts R, et al. 2001. Earliest presence of humans in Northeast Asia. Nature, 413: 413-417 DOI URL

Materials	Field No.	Catalog No. (IVPP)	Context information
Spirocerus wongi
Partial skull with horn-cores	N-07-122	V 28650	E4-8
Juvenile maxilla with DP2-M1	N-06-135	V 28651	E13-5
Left mandible with dp2-m1	N-06-167	V 28652.1	E14-4
Partial right mandible with dp2-m1	N-06-178	V 28652.2	E14-4
Partial right mandible with p4-m3	N-16-046	V 28653	I20-12
Left Mc III+IV	N-11-209	V 28655	H20-9
Right naviculo-cuboid	N-11-042-2	V 28656.1	G21-7
The fused 2nd+3rd tarsals	N-11-042-3	V 28656.2	H20-9
The 1st tarsal	N-11-042-4	V 28656.3	G21-7
Right Mt III+IV	N-11-042-1	V 28656.4	G21-7
Gazella sinensis
Partial skull with horn-cores	N-11-273	V 28657	H22-9
Partial skull with horn-cores	N-06-128	V 28658	E14-2
Partial skull with left horn-core	N-06-237A	V 28659.1	D10-6
Right horn-core	N-06-237B	V 28659.2	D10-6
Partial skull with right horn-core	N-06-166	V 28660	E14-4
Partial skull with right horn-core	N-08-04 (02)	V 28661	H15-2?
Partial skull with left horn-core	N-08-037	V 28662	H16-3
Partial skull with left horn-core	N-08-078	V 28663	G15-6
Partial skull with left horn-core	N-16-029	V 28664	I20-10
Partial skull with right horn-core	N-17-050	V 28665	J15-13
Partial skull with right horn-core	N-17-052	V 28666	J16-13
Partial skull with left horn-core	N-17-064	V 28667	I16-13
Left horn-core	N-07-60	V 28668	E16-11
Left horn-core	N-17-067	V 28669	J16-14
Partial skull with left horn-core	N-18-75	V 28670	I11-13
Partial skull with right horn-core	N-18-85	V 28671	I12-13
Partial skull with left horn-core	N-18-168	V 28672	K13-17
Partial maxilla with P3-M1	2007.9.1	V 28673	F19-1
Partial maxilla with M1-3	N-17-176	V 28674	K16-17
Partial right mandible with p2-m3	N-06-220	V 28675	E12-5
Partial left mandible with p2-p3, m1-3	N-06-222	V 28676	D12-5
Partial right mandible with p4-m3	N-08-048	V 28677	H15-4
Partial left mandible with p4-m3	N-08-068	V 28678	H16-4
Partial right mandible with p3-m3	N-08-067	V 28679	H16-4
Partial left mandible with p2-m3	N-08-069	V 28680	H15-5
Partial right mandible with p2, p4-m3	N-11-250-1	V 28681.1	F20-9
Partial left mandible with p2-m3	N-11-250-2	V 28681.2	F20-9
Left mandible with p3-m3	N-16-086	V 28682	K23-13
Partial left mandible with p4-m3	N-17-081	V 28683	I16-14
Partial right mandible with p4-m3	N-17-162	V 28684	K16-17
Left mandible with dp2-4, m1-2	N-17-164-g	V 28685.1	K16-17
Right mandible with dp2-4, m1-2	N-17-164-d	V 28685.2	K16-17
Partial mandible with p4-m3	N-17-177	V 28686	K16-17
Left humerus (distal)	N-11-174	V 28687	F20-9
Left Mc III+IV	N-15-050	V 28688	H30-3
3rd phalanx	N-15-028	V 28689	G29-4
Left naviculo-cuboid	N-15-125	V 28690	H30-6
Distal part of left tibia	N-15-246	V 28691	F30-3
Left astragalus	N-15-244	V 28692	G29-3
Materials	Field No.	Catalog No. (IVPP)	Context information
Ovis shantungensis
Partial maxilla with left DP4-M1, right DP2-M1	N-07-069-A+B	V 28693	F17-1
Nearly complete left Mc III+IV	N-11-179	V 28694	H23-9
Megalovis piveteaui
Left radius	N-16-051	V 28654	I20-12
Right Mc III+IV	N-17-017	V 28695	I17-10

Materials	Field No.	Catalog No. (IVPP)	Context information
Spirocerus wongi
Partial skull with horn-cores	N-07-122	V 28650	E4-8
Juvenile maxilla with DP2-M1	N-06-135	V 28651	E13-5
Left mandible with dp2-m1	N-06-167	V 28652.1	E14-4
Partial right mandible with dp2-m1	N-06-178	V 28652.2	E14-4
Partial right mandible with p4-m3	N-16-046	V 28653	I20-12
Left Mc III+IV	N-11-209	V 28655	H20-9
Right naviculo-cuboid	N-11-042-2	V 28656.1	G21-7
The fused 2nd+3rd tarsals	N-11-042-3	V 28656.2	H20-9
The 1st tarsal	N-11-042-4	V 28656.3	G21-7
Right Mt III+IV	N-11-042-1	V 28656.4	G21-7
Gazella sinensis
Partial skull with horn-cores	N-11-273	V 28657	H22-9
Partial skull with horn-cores	N-06-128	V 28658	E14-2
Partial skull with left horn-core	N-06-237A	V 28659.1	D10-6
Right horn-core	N-06-237B	V 28659.2	D10-6
Partial skull with right horn-core	N-06-166	V 28660	E14-4
Partial skull with right horn-core	N-08-04 (02)	V 28661	H15-2?
Partial skull with left horn-core	N-08-037	V 28662	H16-3
Partial skull with left horn-core	N-08-078	V 28663	G15-6
Partial skull with left horn-core	N-16-029	V 28664	I20-10
Partial skull with right horn-core	N-17-050	V 28665	J15-13
Partial skull with right horn-core	N-17-052	V 28666	J16-13
Partial skull with left horn-core	N-17-064	V 28667	I16-13
Left horn-core	N-07-60	V 28668	E16-11
Left horn-core	N-17-067	V 28669	J16-14
Partial skull with left horn-core	N-18-75	V 28670	I11-13
Partial skull with right horn-core	N-18-85	V 28671	I12-13
Partial skull with left horn-core	N-18-168	V 28672	K13-17
Partial maxilla with P3-M1	2007.9.1	V 28673	F19-1
Partial maxilla with M1-3	N-17-176	V 28674	K16-17
Partial right mandible with p2-m3	N-06-220	V 28675	E12-5
Partial left mandible with p2-p3, m1-3	N-06-222	V 28676	D12-5
Partial right mandible with p4-m3	N-08-048	V 28677	H15-4
Partial left mandible with p4-m3	N-08-068	V 28678	H16-4
Partial right mandible with p3-m3	N-08-067	V 28679	H16-4
Partial left mandible with p2-m3	N-08-069	V 28680	H15-5
Partial right mandible with p2, p4-m3	N-11-250-1	V 28681.1	F20-9
Partial left mandible with p2-m3	N-11-250-2	V 28681.2	F20-9
Left mandible with p3-m3	N-16-086	V 28682	K23-13
Partial left mandible with p4-m3	N-17-081	V 28683	I16-14
Partial right mandible with p4-m3	N-17-162	V 28684	K16-17
Left mandible with dp2-4, m1-2	N-17-164-g	V 28685.1	K16-17
Right mandible with dp2-4, m1-2	N-17-164-d	V 28685.2	K16-17
Partial mandible with p4-m3	N-17-177	V 28686	K16-17
Left humerus (distal)	N-11-174	V 28687	F20-9
Left Mc III+IV	N-15-050	V 28688	H30-3
3rd phalanx	N-15-028	V 28689	G29-4
Left naviculo-cuboid	N-15-125	V 28690	H30-6
Distal part of left tibia	N-15-246	V 28691	F30-3
Left astragalus	N-15-244	V 28692	G29-3
Materials	Field No.	Catalog No. (IVPP)	Context information
Ovis shantungensis
Partial maxilla with left DP4-M1, right DP2-M1	N-07-069-A+B	V 28693	F17-1
Nearly complete left Mc III+IV	N-11-179	V 28694	H23-9
Megalovis piveteaui
Left radius	N-16-051	V 28654	I20-12
Right Mc III+IV	N-17-017	V 28695	I17-10

Dimensions	S. wongi	S. wongi	S. wongi	S. peii	S. kiakhtensis
Dimensions	This paper	Teilhard and Piveteau (1930)	Bai et al. (2019)	Young (1932)	Dong et al. (2009)
Total length	283	290	264.3-353.8 (288.8)^&	270	151-160. 9^#
Diameter of horn-core base (APD)	64.0-64.2	57-60	51.6-80.2	55	35.9^#
Latero-medial diameter of horn-core base (TD)	49.3-51.4		43.5-54.5
Angle of divergence of horn-cores	50°	57°*	about 70°		50°^#
Cranial width at the horn bases	149.0	144*	134.1
Minimum distance between inner margins of horn processes	65.6	100*	51.7		64.2^#
Distance between the supraorbital foramina (upper margin)	86.7	68.5*	63.2

Dimensions	S. wongi	S. wongi	S. wongi	S. peii	S. kiakhtensis
Dimensions	This paper	Teilhard and Piveteau (1930)	Bai et al. (2019)	Young (1932)	Dong et al. (2009)
Total length	283	290	264.3-353.8 (288.8)^&	270	151-160. 9^#
Diameter of horn-core base (APD)	64.0-64.2	57-60	51.6-80.2	55	35.9^#
Latero-medial diameter of horn-core base (TD)	49.3-51.4		43.5-54.5
Angle of divergence of horn-cores	50°	57°*	about 70°		50°^#
Cranial width at the horn bases	149.0	144*	134.1
Minimum distance between inner margins of horn processes	65.6	100*	51.7		64.2^#
Distance between the supraorbital foramina (upper margin)	86.7	68.5*	63.2

Species		S. wongi	S. wongi	S. wongi	S. peii	S. kiakhtensis	S. kiakhtensis	Ovis shantungensis
Sources		This paper	Teilhard & Piveteau (1930)	Bai et al. (2019)	Young (1932)	Boule et al. (1928)	Dong et al. (2009)	This paper
DP2	L	14.2-14.5	13				10.5	9.5
	W	10-10.2	8				7.7	7.4
DP3	L	19.9-20.3	19-23				12.5	14.8
	W	13.6-14.2	10-12				11.1	12.8
DP4	L	23.5-23.7	22-24				16.5	18.0-18.5
	W	16.8-18.1	12				13.6	15.1-15.5
DP2-4	L	56.2-57.4	52				39.4	41.9
M1	L	26.6-26.7	19?				19.5-24.9	24.0-24.3
	W	15.3	15?				18.2-23.9?	15.7-15.8
dp2	L	10.5-10.8
	W	6.6-6.7
dp3	L	16.4-16.6
	W	9.2
dp4	L	28.2-28.5
	W	11.3-11.6
p4	L	13.6	13-15	17.1	12	15
	W	8.4	9	8.3	9	9
m1	L	17.9	13-20	17.2	15	25?
	W	12.3	11-14	10.7	11	11
m2	L	23.2	21-26	21.6	21	26
	W	12.6	12-13	10.7	11.5	13
m3	L	32.2	32	30.2	32
	W	11.7	11-13	10.1	12
